Specifications
- Brand : Nedis
- Colour : Anthracite
- Device power input connection(s) : DC 3.5 x 1.35 mm
- Ports : 2-Port
- Power adapter cable length: 1.50 m
- Power consumption in standby mode: 1 W
- Power source type: Mains Powered
- Supported resolutions : 720p@60Hz 4K@30Hz 1080i@60Hz 576p@60Hz 480p@60Hz
- Supported technology: 3D HDCP Deep Color 30/36 bit
- Video Accessories: HDMI Splitter
- Width: 154.0 mm
- Aspect ratio: 16:9
- Clock frequency : 340 MHz
- Colour formats: RGB YCbCr 4:4:4 YCbCr 4:2:2
- Connection input: HDMI™ Input
- Connection output : 2x HDMI™ Output
- Depth: 8.0 mm
- Device type: HDMI™ Splitter
- EDID settings: Learn
- Height : 23.0 mm
- Input current: 1.0 A
- Input voltage : 5,0 VDC
- Material : Metal
- Maximum bandwidth: 3.4 Gbps
- Maximum resolution: 4K@30Hz
- Power cable side A : N/A
- Power consumption in operating mode: 1.85 W
- Power plug: Type C (CEE 7/16)
- Resolution standard: 4K UHD
Description
Product Description
With this Nedis® HDMI™ 1 to 2 splitter, you can play movies, give presentations, show pictures, play videogames or duplicate other content from an HDMI™ supported device on 2 other monitors, TVs, or other HDMI™ supportive screens simultaneously. The HDMI™ splitter boosts the signal, which allows you to use longer cables without signal degradation.
4K@30Hz and 3D – And while this splitter supports up to 4K@30Hz resolution, the resolution shown is the resolution of the output device. So, if the output device only has a resolution of Full HD (1080p), and the second screen has a 4K resolution, the 1080p resolution will be shown. The same goes for 3D images and videos.
Plug and Play – With its simple plug-and-play installation it is easy to set it up and to operate. Simply connect your primary HDMI™ device to a maximum of two other HDMI™ supportive screens. Please note that the screen content is duplicated and not extended.
Broad Compatibility – Because this splitter supports 4K@30Hz, 3D, and HDMI™ 1.2 / 1.3 / 1.4, it is compatible with a lot of different screens and devices. For example, duplicate screens from devices with an HDMI™ input: Computer, Xbox 360, Xbox One, PS3, PS4 Pro, Fire Stick, Blu-Ray DVD player, Satellite Receiver, Route Roku, Chromecast, PC, Projectors, etc. Output: HD-Ready, Full HD TVs, Apple TV, Samsung TV, monitors, etc.
Power Adapter – An external power adapter is included with this Nedis® HDMI™ splitter, with this external adapter you don’t have to depend on the power of the HDMI™ devices.
Doesn’t support – Doesn’t support ultra HD 4K@60Hz (3840 x 2160), meaning it transmits 60 images per second, devices that support HDR (High Dynamic Range) and doesn’t support ARC (Audio Return Channel).
FEATURES
- Supports – 4K@30Hz, 3D, HDMI™ 1.2 / 1.3 / 1.4 and HDCP
- EDID function – Set a fixed resolution for all connected devices and screens
- Plug and play – Easy installation and operation
- Duplicates 1 HDMI™™ output into 2 HDMI™ outputs
- Amplifies the digital video signal
Package Contents
Splitter
Power adapter
Quick start guide
