Specifications
- Audio Accessories : HDMI Extender
- Colour: Anthracite
- Audio transmission support: Yes
- Height : 29.0 mm
- Input voltage: 12 V DC
- Maximum bandwidth: 10.2 Gbps
- Maximum resolution: 4K@30Hz
- Transmitter output: 1x RJ45 Female 1x Micro USB
- Width: 90.0 mm
- Aspect ratio: 16:9
- Brand: Nedis
- Clock frequency : 600 MHz
- Depth : 98.0 mm
- Device power input connection(s) : DC 9.0 x 5.5 mm
- Input current : 2.0 A
- IR Return function: Yes
- Material : Metal
- Maximum distance: up to 50.0 m
- Power adapter cable length: 1.00 m
- Power consumption in operating mode: 5 W
- Power consumption in standby mode: 3 W
- Power plug : Type C (CEE 7/16)
- Power source type: Mains Powered
- Receiver input: 1x RJ45 Female 1x Micro USB
- Receiver output : 1x HDMI™ Output
- Resolution standard : 4K UHD
- Supported resolutions: 1080P@60Hz 720p@60Hz 4K@30Hz 1080p@120Hz 480p@60Hz 1080i@30Hz 576p@50Hz
- Supported technology: Dolby True HD HDCP Dolby Digital DTS-HD LPCM DTS Digital Compressed beeps
- Transmission type: Over Cat6
- Transmitter input: 1x HDMI™ Input
Description
Product Description
Extend the HDMI™ connection between your TV and an HDMI screen with up to 50 meters. This Nedis® extender works without signal degradation.
FEATURES
- 4K@30Hz
- Amplification of digital video signals up to 50 m
- Long-distance cover via Cat 5e/6 cables
Package Contents
HDMI extender transmitter unit
HDMI extender receiver unit
Power supply unit
2x IR transmitter unit
2x IR receiver unit
Quick start guide
